Med/Vet Practice Microscope
Not Finding Your Match?Try our Parts Finder!
The UNICO G382PL Microscope is engineered for high-performance viewing with its innovative dual viewing head, allowing two users to observe specimens simultaneously with unparalleled clarity. Featuring two high point eyepieces, this microscope is designed to accommodate users wearing glasses, ensuring a comfortable and unobstructed viewing experience for both individuals.
Equipped with a set of plan achromatic objectives (4X, 10X, 40X, and 100X), the G382PL delivers exceptionally sharp and clear images across a wide range of magnifications. The plan achromatic optics minimize chromatic aberration and ensure superior image quality, making it ideal for precise and detailed analysis.
Whether used in educational settings, research laboratories, or collaborative environments, the UNICO G382PL Microscope provides robust performance and versatility. Its dual viewing capability and high point eyepieces make it a valuable tool for shared observations and detailed examinations.
| Head | Dual Head |
| Eyepiece | 10X WF Hi-EP |
| Objectives | Plan 4X/10X/40X/100X |
| Condenser | NA1.25 |
| Diaphragm | Iris |
| Stage | Mechanical |
| Illumination | LED |
| Bulb | 3 Watt LED |
| Focusing | Coaxial |
| Bodies | |
|---|---|
| G380-3001 | MONOCULAR HEAD, 45° INCLINED FOR G380 |
| G380-3002 | DUAL VIEWING HEAD WITHOUT EYEPIECE FOR G380 SERIES |
| G380-3004 | SEIDENTOPF BINOCULAR HEAD FOR G380 SERIES |
| G380-3005 | SEIDENTOPF TRINOCULAR HEAD FOR G380 SERIES |
| Optics | |
| G380-1402 | HIGH EYEPOINT 10X WIDEFIELD EYEPIECE, F.N. 18, EACH |
| G380-2101 | 4X DIN ACHROMAT OBJECTIVE, N.A. 0.10 FOR G380 SERIES |
| G380-2102 | 10X DIN ACHROMAT OBJECTIVE, N.A. 0.25 FOR G380 SERIES |
| G380-2103 | 40X DIN ACHROMAT OBJECTIVE, N.A. 0.65, RETRACTABLE FRONT LENS FOR G380 SERIES |
| G380-2104 | 100X DIN ACHROMAT OBJECTIVE, N.A. 1.25, OIL, RETRACTABLE FRONT LENS FOR G380 SERIES |
| G380-2301 | 4X DIN PLAN OBJECTIVE, N.A. 0.10 |
| G380-2302 | 10X DIN PLAN OBJECTIVE, N.A. 0.25 |
| G380-2305 | 25X DIN PLAN OBJECTIVE N.A. 0.40 |
| G380-2303 | 40X DIN PLAN OBJECTIVE, N.A. 0.65, RETRACTABLE FRONT LENS |
| G380-2304 | 100X DIN PLAN OBJECTIVE N.A. 1.25, RETRACTABLE FRONT LENS |
| G380-2601 | 4X INFINITY ACHROMAT OBJECTIVE, NA 0.10 |
| G380-2602 | 10X INFINITY ACHROMAT OBJECTIVE, NA 0.25 |
| G380-2603 | 40X INFINITY ACHROMAT OBJECTIVE, NA 0.65 |
| G380-2604 | 100X OIL IMMERSION INFINITY ACHROMAT OBJECTIVE, NA 1.25 |
| G380-2631 | 4X INFINITY PLAN ACHROMAT OBJECTIVE, NA 0.10 |
| G380-2632 | 10X INFINITY PLAN ACHROMAT OBJECTIVE, NA 0.25 |
| G380-2633 | 40X INFINITY PLAN ACHROMAT OBJECTIVE, NA 0.65 |
| G380-2634 | 100X OIL IMMERSION INFINITY PLAN ACHROMAT OBJECTIVE, NA 1.25 |
| Miscellaneous Accessories | |
| G380-5111 | GRADUATED MECHANICAL STAGE (COAXIAL LOW POSITION CONTROLS) FOR G380 SERIES |
| G380-6001 | ABBE CONDENSER, N.A. 1.25, W/ IRIS DIAPHRAGM, SWING-OUT FILTER HOLDER FOR G300 SERIES |
| G380-7001 | LED ILLUMINATOR PACK, SNAP-IN, INCLUDED 3 AA BATTERIES, FOR G380 SERIES ONLY |
| G380-7002 | MIRROR ASSEMBLY, SNAP-IN FOR G380 SERIES ONLY |
| G380-7010 | FIELD DIAGRAM KOEHLER SET FOR G380, G390 SERIES MICROSCOPES |
| G380-8010 | PHOTO LENS AND PHOTO ADAPTER WITH UNIVERSAL THREAD FOR G380 SERIES (REQ. CAMERA AND T-MOUNT) |
| G380-8011 | VERTICAL VIEWING ADAPTER (TO BE INSTALLED ON TRINOCULAR HEAD. REQUIRES EYEPIECE) |
| G380-8031 | PHASE KIT: INCLUDES 40XR SEMI-PLAN PHASE OBJECTIVE AND SLIDE-IN ANNULUS RING FOR G380 SERIES |
| G380-8034 | PHASE KIT: INCLUDES 10X SEMI-PLAN PHASE OBJECTIVE AND SLIDE-IN ANNULUS RING FOR G380 SERIES |
| G380-8032 | SLIDE-IN 40X PHASE ANNULUS RING FOR G380 SERIES |
| G380-8001 | DUST COVER FOR G380 SERIES |
| G380-8906 | DARKFIELD STOP FOR G380 SERIES |
| ATTACHMENT | |
| Size | 9.5 in x 7.5 in x 16 in (240 mm x 190 mm x 410 mm) |
| Shipping Size | 13.5 in x 10.5 in x 17.5 in (340 mm x 260 mm x 440 mm) |
| Weight | 14 lbs (6.4 kg) |
| Shipping Weight | 18 lbs (8.2 kg) |
